Automation Motors – Motors for Curtains
There are many elements in a room décor that not only adds to the beauty and attraction of the space but also adds to the privacy, security and comfort of the inmates. One such element is the curtains. For ages they have been manually operated drapes hanging from pelmets and curtain rods. However now as most parts of the interior décor or various spaces – residential, commercial, industrial, are being touched by automation services even the curtains are getting smarter and motorized.
Automatic curtains are the recent trend dominating the arena of interior décor. As the name indicates these are smart motorized curtains that operate on remote control command.
Fox Domotics curtain motors are designed to automate the opening and closing of curtains, providing convenience, security, and energy efficiency for modern homes. These motors can be integrated into smart home systems, allowing you to control your curtains remotely or through automation routines.
A 5-wire curtain motor is commonly used in automated curtain systems to control the opening and closing of curtains smoothly and efficiently.
Typically, the wires include:
The motor receives commands via the up/down wires to move the curtain track accordingly.
7520-RSDC has combined funtion of KT82TN and KT82TS, controlled by remote controlled and your wired controller.
| Model No | Safety Curtain Weight | Rated Power Input | Open / Close Speed | Rated Current | Continuos Running Time | Ingress Protection | Max. Limit Turns | Track Length | Weight |
|---|---|---|---|---|---|---|---|---|---|
| FDH-45/20-R | 50 (kg) | 45 (kg) | 20 (cm/sec) | 0.34 (A) | 4 min | 20 (IP) | ∝ (Turns) | ≤ 12 (m) | 1.10 (kg) |
| FDH-75/20-R | 70 (kg) | 50 (kg) | 20 (cm/sec) | 0.34 (A) | 4 min | 20 (IP) | ∝ (Turns) | ≤ 12 (m) | 1.10 (kg) |
| FDH-45/20-S | 50 (kg) | 45 (kg) | 20 (cm/sec) | 0.20 (A) | 4 min | 20 (IP) | ∝ (Turns) | ≤ 12 (m) | 1.10 (kg) |
| FDH-75/20-S | 70 (kg) | 50 (kg) | 20 (cm/sec) | 0.20 (A) | 4 min | 20 (IP) | ∝ (Turns) | ≤ 12 (m) | 1.10 (kg) |
A smart curtain motor is an electric device that opens and closes your curtains automatically using a remote, wall switch, or mobile app. Fox Domotics smart motors also work with Alexa, Google Home, and other automation systems for voice control.
Yes, our motorized curtain systems can be easily fitted into existing curtain setups without major modifications. Installation is quick, clean, and compatible with most interiors.
Absolutely. Fox Domotics smart curtain motors integrate seamlessly with Alexa, Google Assistant, and other automation platforms — allowing voice and app control for ultimate convenience.
Our motors are suitable for various window coverings, including drapes, roller blinds, roman shades, and vertical blinds. We also offer customized track systems for large or curved windows.
Key features include electronic memory limit, built-in receiver, light touch-start, power-off manual function, resistance & stop function, and dry contact switch compatibility for automation systems.
All our curtain motors are designed for whisper-quiet performance (below 35 dB), ensuring smooth and silent movement — perfect for bedrooms, offices, or hotels.
Prices for Fox Domotics smart curtain motors vary based on model, length, and automation features. For an accurate quote, please contact our sales team or visit the showroom.
Yes, Fox Domotics provides complete installation support, setup assistance, and reliable after-sales service across India — ensuring hassle-free operation and long-term performance.
Yes, our curtain motors are proudly made in India at our manufacturing facility in Vasai, near Mumbai — combining local innovation with international quality standards.
You can contact our sales team via our website or visit our Mumbai showroom. We assist in choosing the right motor, track system, and automation setup for your space. Whats app no +91 98195 03090
